300L Animal Cell Bioreactor (Upper Magnetic Stirring System) BLBIO-300SCUC
500L Animal Cell Bioreactor (Upper Magnetic Stirring System) BLBIO-500SCUC
Parameter
Description
Total volume
5L,10L,15L,20L,30L,50L,100L,200L,500L,1000L, 5KL, 10KL etc.
Working volume
30%~70%
Tank
Inside electrolytic polishing, precision: 0.2-0.4um. Diameter and height ratio 1:1.5
Stirring system
Magnetic drive, low shear mixing blades. Stir speed: 30~300rpm
Sterilization
Sterilize in place (SIP), auto control by program
Clean
Clean in place by spray ball
Gas control
Provision for mixing at least four gases (Air, Oxygen, Nitrogen and CO2) Auto control by mass flow meter. Air flow 1vvm, O2/N2/CO2 0.1vvm.
Feeding
Automatically feeding by peristaltic pump
Anti-foam control
Automatically add antifoamer by peristaltic pump
Temperature control
Auto-control, electric heating range: water source add 5℃ to 70℃
PH control
PH 2.00-12.00±0.1, auto-control adding acid/base by peristaltic pump, pH sensor from Hamilton/Mettler, Switzerland.
Do control
0-150±3% displaying precision 0.1%, DO sensor from Hamilton/Mettler, Switzerland. DO coupling with agitation, oxygen.
Sampling valve
Can sterilization separately, manual
Harvest
Zero dead zone bottom valve, can sterilization separately, manual
Weight system
Mettler-Toledo, Switzerland
Pressure
Auto control, BD Germany pressure transmitter or Lambert differential pressure liquid level gauge.
Exhaust
Have condenser before exhaust, control by diagram valve / Proportional control valve.
Control parameters
10 or 15 inch touch screen, Siemens PLC with control parameters (stirring, pH, DO, temperature, feeding, alarm, gas etc.), data analysis, data record, data output, language(RU/EN/CN) and other customized functions
Optional configuration
Remote control, Mass flow meter(auto control gas), exhaust heating, exhaust filter, gas(CO2) exhaust analysis, Level sensor, Turbidity(OD) sensor, ORP sensor, Weight system, Live cell sensor（Biomass）, Printing, Siemens touch screen, Double mechanical seal, 4-valves-group for feeding, Bottom valve auto, ASME certificate, CSA certificate, air flow 2vvm, etc.
Fermenter Description:
BLBIO GJ series fermentation system is a set of laboratory glass fermentation equipment with powerful functions, which can meet various purposes of fermentation, such as batch, batch fed, and even animal cell culture.
The 10inch color touch screen is used to display all measured values and control parameters, which greatly facilitates the user’s operation. 4 peristaltic pumps are installed on the front of the control box, which can replenish acid, alkali, defoamer and medium to the fermenter.
Various parameters in fermentation such as pH, DO, temperature and rotational speed can be monitored by the controller, and all data and control parameters can be transmitted to the controller or computer.
The structure is compact, and various components can be integrated on the fermentation system.
The upper-driven direct-coupling mechanical stirring ,with simple structure and stable operation.
