Laboratory Spray Dryer

BLBIO-8000 Laboratory Spray Dryer (Experimental Spray Dryer) is the crystallization of Shanghai Bailun Biotechnology Co., Ltd. carefully developed in the field of experimental spray drying. The compact design of the machine allows it to be placed in the laboratory (it can be moved freely), and it is self-contained and can be operated without additional facilities. One-button start-up, large color LCD touch screen operation, can adopt two operation modes of automatic or manual monitoring, which is convenient for operation and monitoring of the experimental process. It is a spray dryer with small size, low noise and excellent drying effect.

Scope of application:

BLBIO-8000 experimental spray dryer is mainly suitable for the production of trace granular powder in universities, research institutes and laboratories of food, pharmaceutical and chemical enterprises, and has broad-spectrum applicability to all solutions such as emulsions and suspensions, and is suitable for the drying of heat-sensitive substances such as biological products, biological pesticides, enzyme preparations, etc., because the sprayed materials are only subjected to high temperature when sprayed into mist size particles, so they are only heated instantaneously, which can keep these active materials from being destroyed after drying.

BLBIO-8000 Experimental Spray Dryer Key Features:

Large color touch screen operation, combination of fully automatic control and manual control:

Fully automatic control: one-button start-up, after setting the spray process parameters, the temperature reaches the predetermined temperature, the peristaltic pump starts by itself, the operation animation is displayed on the touch screen, and the operation process is clearly displayed; When shutting down, just press the stop button, and the machine will automatically shut down safely.

Manual control: If you need to adjust the process parameters during the experiment, you can easily switch to the manual state, and the color touch screen will display (animation) dynamically during the whole experiment.

Shutdown protection function: When shutting down, you only need to press the stop button, and the machine will stop running immediately except for the fan, so as to ensure that the equipment will not burn out due to misoperation (forcibly turning off the fan).

The spray, drying and collection system is made of transparent high-quality borosilicate heat-resistant glass material, which makes the spray drying process in a pollution-free and most stable environment, and makes the entire spray drying experimental process directly observable, which provides great convenience for researchers to control the experimental process and experimental results, and can find and solve problems in time. All glass elements are easy to disassemble and easy to clean.

The particle diameter of the powder spraying is normally distributed, the fluidity is very good, and the noise of the equipment is very low, less than 60db, which meets the noise standard of the national laboratory;

The atomization structure of the two-fluid spray, the whole machine is made of high-quality stainless steel material precision sandblasting electrolysis, compact design, no auxiliary equipment, easy to use, and updated for a long time.

In order to meet the requirements of adjusting various parameters in the experimental range, the PID constant temperature control technology was used in the design of drying temperature control, so that the temperature control of the whole temperature zone was accurate, and the heating temperature control accuracy was ± 1°C.

Equipped with an air inlet filter to keep the sample pure.

The feed volume can be adjusted by the feed peristaltic pump, and the minimum sample volume can reach 50 ml.

For liquids that are prone to sedimentation, a magnetic stirrer can be used to keep the feed uniform and consistent, without sedimentation

After drying, the particle size of the finished dry powder is relatively uniform, and more than 95% of the dry powder is in the same particle size range.

For viscous materials, there is a nozzle cleaner (through needle), which will automatically remove when the nozzle is blocked, and the frequency of the needle can be automatically adjusted.
